| Werkstoff Gehäuse | PA-reinforced PC | ||
| Sensor type | +/-10 V +/-20 mA +/-5 V 0 - 10 V 0 - 20 mA 1-5 V 4 - 20 mA | ||
| Data format | 15 bits + prefix Scalable to 15 bits | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Isolation channel - channel | no | ||
| Nennbetriebsspannung DC | 24 V | ||
| Basic error limit at 25 °C | ±0.2% | ||
| Intern power consumption nominal operating voltage | Typ. 50 mA | ||
| Fuse protection (short circuit) | Internal electronic fuse | ||
| Internal cycle time | 500 µs | ||
| Parameterisation | Data format Forcing per channel Limit monitoring per channel Measured value smoothing Sensor supply active Signal range per channel Behaviour after short circuit Behaviour after input overload Wire break monitoring per channel | ||
| Number of inputs | 4 |
| Werkstoff-Hinweis | RoHS-compliant | ||
| Max. Leitungslänge | 30 m Shielded | ||
| Produktgewicht | 46 g | ||
| Schutzart | Dependent on the manifold block | ||
| Korrosionsbeständigkeitsklasse KBK | 1 - Low corrosion stress (when installed) | ||
| Isolation channel - internal bus | Yes, without using the internal sensor supply | ||
| Nominal DC operating voltage, load voltage | 24 V +/-2% | ||
| Operating error limit related to the ambient temperature range | ±0.3% | ||
| Betriebsspannungsbereich DC | 18 V ... 30 V | ||
| Wiederholgenauigkeit | 0.1% at 25ºC | ||
| LED display | 1 Group diagnostics 4 channel diagnostics | ||
| Diagnosis | Wire break per channel Limit value violation per channel Parameterisation error Overflow/underflow Input overload Short circuit of sensor supply | ||
| Abmessungen B x L x H | (incl. interlinking block and connection technology) 50 x 107 x 50 mm |
