| Werkstoff Gehäuse | PA-reinforced PC | ||
| Characteristic for outputs | Based on IEC1131-T2 | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Isolation channel - channel | no | ||
| Nennbetriebsspannung DC | 24 V | ||
| Max. power supply per channel | 1 A (24 W lamp load) | ||
| Betriebsspannungsbereich DC | 18 V ... 30 V | ||
| LED display | 1 Group diagnostics 4 channel diagnostics 4 Channel status | ||
| Diagnosis | Short circuit/overload per channel Undervoltage of outputs | ||
| Abmessungen B x L x H | (incl. interlinking block and connection technology) 50 x 107 x 50 mm |
| Switching logic for outputs | PNP (positive switching) | ||
| Produktgewicht | 42 g | ||
| Schutzart | Dependent on the manifold block | ||
| Korrosionsbeständigkeitsklasse KBK | 1 - Low corrosion stress (when installed) | ||
| Isolation channel - internal bus | Yes, with intermediate air supply | ||
| Max. residual current outputs per module | 4 A | ||
| Intern power consumption nominal operating voltage | Typ. 16 mA | ||
| Fuse protection (short circuit) | Internal electronic fuse per channel | ||
| Parameterisation | Fail-safe per channel Forcing per channel Idle mode per channel Behaviour after short circuit Module monitoring | ||
| Number of outputs | 4 |
