| Werkstoff Gehäuse | PA-reinforced PC | ||
| Max. Leitungslänge | 30 m Shielded | ||
| Produktgewicht | 47 g | ||
| Schutzart | Dependent on the manifold block | ||
| Korrosionsbeständigkeitsklasse KBK | 1 - Low corrosion stress (when installed) | ||
| Isolation channel - internal bus | Yes, without using the internal sensor supply | ||
| Basic error limit at 25 °C | ±0.5% | ||
| Intern power consumption nominal operating voltage | Typ. 50 mA | ||
| Fuse protection (short circuit) | Internal electronic fuse | ||
| Internal cycle time | 10 ms | ||
| Parameterisation | Data format Forcing per channel Limit monitoring per channel Measured value smoothing Signal range per channel Behaviour after short circuit Wire break monitoring per channel | ||
| Number of inputs | 4 |
| Sensor type | 0 - 20 mA 4 - 20 mA | ||
| Data format | 12 bits + prefix Scalable to 15 bits | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Isolation channel - channel | no | ||
| Nennbetriebsspannung DC | 24 V | ||
| Operating error limit related to the ambient temperature range | ±0.6% | ||
| Betriebsspannungsbereich DC | 18 V ... 30 V | ||
| Wiederholgenauigkeit | 0.15% at 25°C | ||
| LED display | 1 Group diagnostics | ||
| Diagnosis | Wire break per channel Limit value violation per channel Short circuit, input signal Parameterisation error | ||
| Abmessungen B x L x H | (incl. interlinking block and connection technology) 50 x 107 x 50 mm |
