| Werkstoff Gehäuse | PA-reinforced PC | ||
| Max. Leitungslänge | 50 m Shielded | ||
| Produktgewicht | 46 g | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Isolation channel - channel | no | ||
| Nennbetriebsspannung DC | 24 V | ||
| Basic error limit at 25 °C | ±0.4% | ||
| Intern power consumption nominal operating voltage | 30 mA | ||
| Fuse protection (short circuit) | Internal electronic fuse per channel | ||
| Internal cycle time | 250 ms | ||
| Parameterisation | Limit monitoring per channel Cold junction compensation Unit of measurement Measured value smoothing Sensor type per channel Wire break monitoring per channel | ||
| Number of inputs | 4 |
| Sensor type | Type B Type E Type J Type K Type N Type R Type S Type T | ||
| Data format | 15 bits + prefix Binary notation in tenths of a degree | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Korrosionsbeständigkeitsklasse KBK | 1 - Low corrosion stress (when installed) | ||
| Isolation channel - internal bus | yes | ||
| Max. line resistance | 10 ohm/conductor | ||
| Operating error limit related to the ambient temperature range | ±0.6% | ||
| Betriebsspannungsbereich DC | 18 V ... 30 V | ||
| Wiederholgenauigkeit | 0.05% at 25ºC | ||
| LED display | 1 Group diagnostics 4 channel diagnostics | ||
| Diagnosis | Wire break per channel Limit value violation per channel Parameterisation error | ||
| Abmessungen B x L x H | (incl. interlinking block and connection technology) 50 x 107 x 50 mm |
