| Werkstoff Gehäuse | PA-reinforced PC | ||
| Characteristic for inputs | IEC1131-T2 | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Switching level | Signal 0: >= 11 V Signal 1: <= 5 V | ||
| Isolation channel - internal bus | no | ||
| Max. residual current of inputs per module | 0,7 A | ||
| Betriebsspannungsbereich DC | 18 V ... 30 V | ||
| Input debounce time | 3 ms (0.1 ms, 10 ms, 20 ms, parameterisable) | ||
| Parameterisation | Input debounce time Signal extension time Behaviour after short circuit Module monitoring | ||
| Number of inputs | 8 |
| Switching logic for inputs | NPN (negative switching) | ||
| Produktgewicht | 40 g | ||
| Schutzart | Dependent on the manifold block | ||
| Korrosionsbeständigkeitsklasse KBK | 1 - Low corrosion stress (when installed) | ||
| Isolation channel - channel | no | ||
| Nennbetriebsspannung DC | 24 V | ||
| Intern power consumption nominal operating voltage | Typ. 15 mA | ||
| Fuse protection (short circuit) | Internal electronic fuse per module | ||
| LED display | 1 Group diagnostics 8 Channel status | ||
| Diagnosis | Short circuit/overload per channel | ||
| Abmessungen B x L x H | (incl. interlinking block and connection technology) 50 x 107 x 50 mm |
