| Werkstoff Gehäuse | PA | ||
| Befestigungsart | With H-rail | ||
| Feldbus-Schnittstelle, Protokoll | Ethernet OPC-UA | ||
| Feldbus-Schnittstelle, Anschlusstechnik | M12x1, D-coded to EN 61076-2-101 | ||
| Fieldbus interface, function | Bus connection to Ethernet-based Festo devices | ||
| Ethernet interface, protocol | TCP/IP | ||
| Ethernet interface, transmission rate | 10 Mbit/s 100 Mbit/s | ||
| Ethernet interface, connection system | M12x1, D-coded to EN 61076-2-101 | ||
| Field bus interface, transmission rate | 100 Mbit/s | ||
| Produktgewicht | 130 g | ||
| Schutzart | IP65 IP67 | ||
| Relative Luftfeuchtigkeit | 95 % Non-condensing | ||
| Korrosionsbeständigkeitsklasse KBK | 0 - No corrosion stress | ||
| Schwingfestigkeit | Transport application test with severity level 1 to FN 942017-4 and EN 60068-2-6 | ||
| Permissible voltage fluctuations for electronics/sensors | ± 25% | ||
| Nominal DC operating voltage, electronics/sensors | 24 V | ||
| Intrinsic current consumption at nominal operating voltage for electronics/sensors | Typically 80 mA | ||
| Configuration support | Integrated web server | ||
| CPU data | 256 MB RAM Dual Core 533 MHz | ||
| Abmessungen B x L x H | 50 x 107 x 50 mm |
| Werkstoff-Hinweis | RoHS-compliant | ||
| Fieldbus interface, connection pattern | 00995716 | ||
| Feldbus-Schnittstelle, Anzahl Pole/Adern | 4 | ||
| Feldbus-Schnittstelle, Anschlussart | Socket | ||
| Ethernet interface, connection pattern | 00995716 | ||
| Ethernet interface, function | Connection to MQTT broker | ||
| Ethernet interface, number of pins/wires | 4 | ||
| Ethernet interface, connection type | Socket | ||
| Field bus interface, electrical isolation | yes | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Protection against direct and indirect contact | PELV | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Schockfestigkeit | Shock test with severity level 1 to FN 942017-5 and EN 60068-2-27 | ||
| CE-Zeichen (siehe Konformitätserklärung) | To EU EMC Directive | ||
| Power failure bridging | 10 ms | ||
| IP address setting | DHCP Static via web server | ||
| Operator controls | DIP switch for resetting to delivery state Rotary switch for setting operating mode | ||
| Diagnostics via LED | Modify Module location Network status Network status, port 1 Network status, port 2 Power supply, electronics/sensors Load power supply System fault Connection to the cloud | ||
| Rastermaß | 50 mm |
