| Werkstoff Gehäuse | PA-reinforced PC | ||
| Befestigungsart | On interlinking block CPX-M-GE.. | ||
| Characteristic for inputs | To EN 60947-5-6 | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Relative Luftfeuchtigkeit | 95 % Non-condensing | ||
| Zulässige Spannungsschwankungen | +/- 25% | ||
| Restwelligkeit | 0.4 Vpp | ||
| Isolation channel - internal bus | yes | ||
| Nennbetriebsspannung DC | 24 V | ||
| Fuse protection (short circuit) | Per channel | ||
| LED display | 1 Group diagnostics 8 channel diagnostics 8 Channel status | ||
| Zusatzfunktionen | Frequency measurement Counter function | ||
| Diagnosis | Wire break per channel Limit value violation per channel Short circuit per channel Parameterisation error | ||
| Rastermaß | 50 mm | ||
| Parameterisation | Data format Input debounce time per channel Input function per channel Replacement value in diagnostic case per channel Signal extension time per channel Gate time per channel Monitoring limit values per channel Monitoring of short circuit per channel Parameter monitoring Counter configuration per channel Upper limit per channel Lower limit value per channel Wire break monitoring per channel |
| Werkstoff-Hinweis | RoHS-compliant | ||
| Max. Leitungslänge | 200 m | ||
| Produktgewicht | 100 g | ||
| Schutzart | Dependent on the manifold block | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Switching level | To EN 60947-5-6 | ||
| Isolation channel - channel | no | ||
| Power failure bridging | 20 ms | ||
| Intern power consumption nominal operating voltage | Typ. 75 mA | ||
| Input debounce time | 3 ms (0 ms, 10 ms, 20 ms, parameterisable) | ||
| Operator controls | DIL switch | ||
| Verpolungsschutz | For operating voltage | ||
| Number of inputs | 8 | ||
| Abmessungen B x L x H | (incl. interlinking block and connection technology) 50 x 107 x 70 mm |
