EATON 270335

Name: 270335 EATON
Brand: EATON
SKU: 801864-de-eur
Price: 50.32 EUR
Availability: InStock

z-s230/4s

50,32 € ~~62,90 €~~ -19%

8 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Einbaulage	din rail
Breite	35 mm

Gewicht	263g

voltage type		ac
supply voltage - min		240 v
number of contacts (normally open contacts)		4
incandescent lamp load - max		0 w
functions		mechanical switch
control voltage 1 type		ac
heat dissipation per pole, current-dependent		1.5 w
ambient operating temperature - max		45 °c
control voltage 1 - max		230 v
control voltage 2 - min		0 v
width in number of modular spacings		2
frequency control voltage 2 - min		0 hz
control voltage 1 - min		230 v
control voltage 2 type		ac
rated switch current		16 a
compliances		rohs conform
product width		35 mm
product length/depth		80 mm

switching current (cos phi = 0.6) - max		0 a
equipment heat dissipation, current-dependent		6 w
ambient operating temperature - min		-20 °c
supply voltage - max		415 v
built-in depth		60 mm
load fluorescent lamp - max		0 va
frequency control voltage 1 - min		50 hz
frequency control voltage 2 - max		0 hz
load fluorescent lamp (parallel compensated) - max		0 va
operating mode		manual operation possible
frequency control voltage 1 - max		50 hz
control voltage 2 - max		0 v
load fluorescent lamp (duo circuit) - max		0 va
mounting method		din rail
rated operational current for specified heat dissipation (in)		16 a
Produktgewicht		.263 kg
product height		70 mm
ean		4015082703356
