| Werkstoff Gehäuse | PA-reinforced | ||
| Werkstoff-Hinweis | RoHS-compliant | ||
| LED display, product-specific | 1 hp electrical operating voltage 16 Channel status 2 Group diagnostics | ||
| Elektrischer Anschluss | 16x socket 3-pin M8 | ||
| Characteristic for inputs | IEC1131-T2 | ||
| IO-Link, Prozessdatenbreite IN | 2 bytes | ||
| IO-Link, Port class | B | ||
| IO-Link, Protokollversion | Device V 1.0 | ||
| Protokoll | I-Port IO-Link® | ||
| Umgebungstemperatur | -5 °C ... 50 °C | ||
| Lagertemperatur | -20 °C ... 70 °C | ||
| Zertifikat ausstellende Stelle | UL E239998 | ||
| KC-Zeichen | KC-EMV | ||
| Current consumption at nominal operating voltage, logic | ≤ 35 mA | ||
| Isolation channel - channel | no | ||
| Max. number of inputs | 16 | ||
| Input debounce time | 0.5 ms (3 ms, 10 ms, 20 ms, parameterisable) | ||
| Baud rate | 38.4 kbit/s, 230.4 kbit/s | ||
| Verpolungsschutz | For operating voltage |
| Werkstoff Deckel | PA-reinforced | ||
| Befestigungsart | With through-hole With H-rail Either: | ||
| LED display, bus-specific | X20: I-Port/IO-Link® | ||
| Switching logic for inputs | PNP (positive switching) | ||
| IO-Link, minimale Zykluszeit | Device 3.2 ms | ||
| IO-Link, Number of ports | 1 | ||
| IO-Link, Communication mode | COM2 (38.4 kBaud), COM3 (230.4 kBaud) | ||
| IO-Link, connection technology | Device, 5-pin | ||
| Produktgewicht | 250 g | ||
| Schutzart | IP65 IP67 | ||
| Korrosionsbeständigkeitsklasse KBK | 2 - Moderate corrosion stress | ||
| CE-Zeichen (siehe Konformitätserklärung) | To EU EMC Directive | ||
| Zulassung | RCM trademark c UL us listed (OL) | ||
| Switching level | Signal 0: <= 5 V Signal 1: >= 11 V | ||
| Nennbetriebsspannung DC | 24 V | ||
| Max. total current per module | 1,2 A | ||
| Betriebsspannungsbereich DC | 18 V ... 30 V | ||
| Fuse protection (short circuit) | Internal electronic fuse protection for each group | ||
| Abmessungen B x L x H | 143 x 103 x 32 mm |
