| Ausführung | no | ||
| Medium | compressed air | ||
| min. ambient temperature | -20 °c | ||
| min. medium temperature | -20 °c | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| logic function | not (no) | ||
| working pressure min. | 1.5 bar | ||
| control pressure min. | 1.05 bar | ||
| throttle | with throttle | ||
| Gehäusematerial | polyoxymethylene |
| time delay | 10 s | ||
| max. particle size | 5 µm | ||
| max. ambient temperature | 70 °c | ||
| max. medium temperature | 70 °c | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| nominal flow qn | 120 l/min | ||
| working pressure max | 10 bar | ||
| control pressure max. | 7 bar | ||
| Gewicht | 0.125 kg | ||
| seal material | acrylonitrile butadiene rubber |
