| seal material | acrylonitrile butadiene styrene | ||
| Gehäusematerial | polyamide fiber-glass reinforced | ||
| pointer color | black | ||
| color for differential pressure range | red, green | ||
| main scale unit (outside) | bar | ||
| max. ambient temperature | 60 °c | ||
| working pressure max | 16 bar | ||
| display range max. | 0.5 bar | ||
| range of application max. | 0.5 bar | ||
| scale value | 0,10 | ||
| mounting orientation | vertical | ||
| flange version | flange version |
| material viewing window | polystyrene | ||
| Gewicht | 0.127 kg | ||
| background color | white | ||
| main scale color (outside) | black | ||
| Medium | compressed air | ||
| min. ambient temperature | 0 °c | ||
| working pressure min. | 0 bar | ||
| display range min. | 0 bar | ||
| range of application min. | 0 bar | ||
| atex | suitable for atex | ||
| viewing window | polystyrene | ||
| Typ | diaphragm pressure gauge |
