FESTO VUWG
61 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VUWG – Pneumatic valve. Finden Sie das passende Produkt durch Filtern mit Directional control valve type, Baugröße, Ventilfunktion, Reset method for monostable/single solenoid valves, Pneumatischer Anschluss und Exhaust.
VUWG Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VUWG | VUWG- - - - | Pneumatic valve |
Typcode zur Katalognummer VUWG,
VUWG- - - -
| 001 | Series |
|---|---|
| VUWG | Pneumatic valve |
| 002 | Directional control valve type |
| L | In-line valve |
| S | Semi-inline valve |
| B | Sub-base valve |
| 003 | Size |
| 10A | Size 10, deviating fl ow |
| 10 | Size 10 |
| 14 | Size 14 |
| 18 | Size 18 |
| 004 | Valve function |
| T32U | 2x3/2-way valve, normally open |
| T32C | 2x3/2-way valve, normally closed |
| T32H | 2x3/2-way valve, 1x normally closed, 1x normally open |
| M52 | 5/2-way valve, monostable |
| B52 | 5/2-way valve, bistable |
| P53U | 5/3-way valve, mid-position pressurised |
| P53E | 5/3-way valve, mid-position exhausted| |
| P53C | 5/3-way valve, mid-position closed |
| 005 | Reset method for monostable/single solenoid valves |
| None | |
| A | Pneumatic spring |
| E | Pneumatic spring, external |
| M | Mechanical spring |
| R | Mixed, pneumatic/mechanical spring |
| X | Mixed, pneumatic/mechanical spring, external |
| 006 | Pneumatic connection |
|---|---|
| F | Flange/sub-base |
| M3 | M3 |
| M5 | M5 |
| M7 | M7 |
| G18 | G1/8 |
| G14 | G1/4 |
| Q3 | Push-in connector 3 mm |
| Q4 | Push-in connector 4 mm |
| Q4H | Push-in connector 4 mm, with connecting thread M7 |
| Q6 | Push-in connector 6 mm |
| Q6H | Push-in connector 6 mm, with connecting thread M7 |
| Q8 | Push-in connector 8 mm |
| Q10 | Push-in connector 10 mm |
| T18 | Push-in connector 1/8” |
| T532 | Push-in connector 5/32” |
| T316 | Push-in connector 3/16” |
| T316H | Push-in connector for 3/16”, M7 |
| T14 | Push-in connector 1/4” |
| T14H | Push-in connector for 1/4”, M7 |
| T38 | Push-in connector 3/8” |
| T516 | Push-in connector 5/16” |
| 007 | Exhaust |
| No fitting | |
| QN | With fitting |
| U | Silencer |
