| min. medium temperature | -20 °c | ||
| stroke max. | 1200 mm | ||
| weight 0 mm stroke | 0.58 kg | ||
| Dämpfungslänge | 19 mm | ||
| Anschlüsse | g 1/4 | ||
| working pressure min. | 1 bar | ||
| min. ambient temperature | -20 °c | ||
| retracting piston force | 660 n | ||
| scraper | standard | ||
| environmental requirements | industry standard, atex optional | ||
| Dämpfung | pneumatic adjustable cushioning | ||
| Hub | 500 mm | ||
| Typ | version: standard type |
| Medium | compressed air | ||
| weight +10 mm stroke | 0.024 kg | ||
| cushioning energy | 9 j | ||
| Kolbenstangengewinde | m12x1,25 | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 80 °c | ||
| extracting piston force | 790 n | ||
| pressure for determining piston forces | 6,3 bar | ||
| piston rod | single | ||
| magnetic piston | piston with magnet | ||
| Funktionsprinzip | double-acting | ||
| piston Ø | 40 mm |
