| indirect mounting for series | pra, its, rtc, cvi | ||
| cable | with cable | ||
| quiescent current (without load) | < 35 ma | ||
| Ausgangsignal | 0 - 10 v dc, 4 - 20 ma | ||
| sampling interval | 1,15 ms | ||
| Schutzklasse | ip65, ip67 | ||
| max. ambient temperature | 70 °c | ||
| max. measuring range resolution | typ. 0,03 % fsr | ||
| Schockfestigkeit | 30 g / 11 ms | ||
| Anzeige | 2 led |
| Elektrischer Anschluss | plug | ||
| Kabellänge | 0.3 m | ||
| repetitive precision max. measuring range | typ. 0,06 % fsr | ||
| Restwelligkeit | ≤ 10 % | ||
| certificates | culus | ||
| min. ambient temperature | -20 °c | ||
| max. measuring range | 323 mm | ||
| linearity deviation | 0,5 mm | ||
| Schwingfestigkeit | 10 - 55 hz, 1 mm | ||
| Gehäusematerial | aluminum |
