| electrical connection type | plug (male) | ||
| Number of outputs | 1 | ||
| max. number of ddl participants | 14 | ||
| max. power consumption per coil | 0.2 ma | ||
| Schutzklasse | ip65 | ||
| actuator voltage tolerance | 0% / +10% | ||
| power consumption electronics | 0.3 a | ||
| operational voltage electronics | 24 v dc | ||
| max. ambient temperature | 50 °c | ||
| fieldbus design | s-design | ||
| electrical connection number of poles | 4-pin | ||
| fieldbus protocol | ethernet/ip, modbus tcp, tcp/ip |
| port valve system | d-sub | ||
| Number of inputs | 1 | ||
| Max. Leitungslänge | 40 m | ||
| data transfer bit | 128 bit | ||
| total current for actuators | 3 a | ||
| operating voltage, actuators | 24 v dc | ||
| electronics voltage tolerance | -20% / +20% | ||
| number of solenoid coils max. | 24 | ||
| min. ambient temperature | 5 °c | ||
| electrical connection coding | a-coded | ||
| electrical connection size | m12 | ||
| Ausführung | bus coupler with driver |
