1)
Set screw M3
2)
Activation point
| Aktivierungspunkt (Dimension "X") | 13,65 | mm |
| Funktionsprinzip | Magnetic | ||
| Laststrom | ≤ 20 | ||
| Anschlussart | Line 0.3 m and plug M8x1 3-pin with knurled screws | ||
| Kurzschlussschutz | ‒ | ||
| Einschaltimpulsunterdrückung | ‒ | ||
| Impulsverzögerung (Ausschaltverzögerung) | ‒ | ||
| Geeignet für flexible Installation (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Schweißfunkenbeständig (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Kabeldurchmesser D (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | 3.2 mm ±0.2 | ||
| Biegeradius, Biegen (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Maximal zulässige Fahrgeschwindigkeit (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Zulässige Umgebungstemperatur (min ... max) | -40 °C ... +85 °C | ||
| MTTFd (gemäß EN ISO 13849-1) | ‒ |
| Betriebsspannung | 3,8 ... 30 | ||
| Schaltfunktion | Hall PNP/normally closed (NC) | ||
| Funktionsanzeige | ‒ | ||
| Verpolungsschutz | ‒ | ||
| Schaltfrequenz | 2,50 | kHz | |
| Maximal zulässige Anlaufgeschwindigkeit | 2 | m/s | |
| Kann Torsion standhalten (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Leitungsquerschnitt (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | 3x0,14 | ||
| Biegeradius, stationär (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Biegezyklen (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Maximal zulässige Beschleunigung (Technical data only for the cast-on connection line (0.3 m) at the magnetic sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Schutzart | IP66 | ||
| Zertifizierungen und Zulassungen | ‒ |
