1)
Cable length 10 m
2)
Activation point
3)
Active surface
4)
Set screw for retention
| Aktivierungspunkt (Dimension "X") | 9 | mm |
| Biegeradius, stationär (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Biegezyklen (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Maximal zulässige Beschleunigung (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Schutzart | IP66 | ||
| Zertifizierungen und Zulassungen | ‒ | ||
| Kontakttyp | 0 | ||
| Stromaufnahme | 0 | ||
| Schaltspannung | 0 | ||
| Kabellänge | 0 | ||
| Laststrom | 500 | mA | |
| Anschlussart | Line 2.0 m, 3-pin | ||
| Funktionsanzeige | ‒ | ||
| Verpolungsschutz | ‒ | ||
| Schaltfrequenz | 2,50 | kHz | |
| Maximal zulässige Anlaufgeschwindigkeit | 2 | m/s | |
| Kann Torsion standhalten (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Leitungsquerschnitt (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | 3x0,14 |
| Biegeradius, Biegen (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Maximal zulässige Fahrgeschwindigkeit (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Zulässige Umgebungstemperatur (min ... max) | -40 °C ... +85 °C | ||
| MTTFd (gemäß EN ISO 13849-1) | ‒ | ||
| Funktionsprinzip | Magnetic | ||
| Betriebsspannung | ≤ 30 | ||
| Ausgangsstrom | 0 | ||
| Schaltstrom | 0 | ||
| Gehäuseschutzklasse | 0 | ||
| Schaltfunktion | REED / changeover contact (NC: C+NC, NO: C+NO) | ||
| Anschlussenden verzinnt | ✔ | ||
| Kurzschlussschutz | ‒ | ||
| Einschaltimpulsunterdrückung | ‒ | ||
| Impulsverzögerung (Ausschaltverzögerung) | ‒ | ||
| Geeignet für flexible Installation (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Schweißfunkenbeständig (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | ‒ | ||
| Kabeldurchmesser D (Technical data only for the cast-on connection line at the sensor. Even more performance, e.g. extension cables are offered for use in a cable management chain. ) | 3.2 mm ±0.2 |
