REXROTH R108122000 linear-set

LSGF-M-20-DD

84,27 €
10 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

  • Lightweight precision housing (aluminum)
  • Standard Linear Bushing
  • Secured by grooved taper pin
  • External seals
  • No lube port

Typ (LSG) Linear sets Flanged, R1081
Form (F) Flanged
Baureihe (M) Standard linear bushing
Wellendurchmesser (20) 20 Shaft diameter
Dichtungen (DD) With two seals
D 32 mm
D1 35 mm +0.8
e 42 mm ±0.15
L1 18 mm
S 6,60
W 13,50 mm
B (Dimensional tolerance ISO 8062-3 - DCTG 9.) 60
D2 (Dimensional tolerance ISO 8062-3 - DCTG 9.) 42 mm
Linie 45 mm
L1 18 mm
Ventil (Dimensional tolerance ISO 8062-3 - DCTG 9.) 10 mm
amax 100 m/s²
Maschinenschutz 0,33 kg
Losbrechkraft 12 N
Betriebsbedingungen Operating conditions
vmax 2,50 m/s
FR (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. ) 4 N
Radialspiel der Welle h6 (Determined from working bore diameter and shaft tolerance statistics. When factoring in the outer diameter of the Linear Bushings and the housing bore, an h6 shaft produces similar radial clearance values as specified in the "H6H7" column under "Radial clearance" for the R0610 standard Linear Bushing. ) + 23
+ 6
Zulässige Umgebungstemperatur (min ... max) (for standard Linear Bushings without wiper seals) -10 °C ... +100 °C
84,27 €
Lagerbestand 10 Stk.
Teilenummer R108122000
Hersteller REXROTH
Menge Stückpreis
1+ 84,27 €
