REXROTH R074150800 FLANSCH-KUGELBUECHSE

Name: R074150800 REXROTH
Brand: REXROTH
SKU: 433513-de-eur
Price: 122.9 EUR
Availability: InStock

KBMFT-8-DD

122,90 €

14 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Rugged all-metal design with steel ball retainer for harsh environments and heavy contamination
Many pockets acting as lubricant reservoirs for extended lubrication intervals or lubrication for life
For use in woodworking, foundries, cement plants
Stainless steel for the medical, chemistry and food industries
Integrated wiper seals

Typ (KB)	Standard linear bushings Flanged tandem, R0741
Baureihe (M)	Standard (metal)
Form (FT)	Flanged Tandem

Wellendurchmesser (8)	8 Shaft diameter
Dichtungen (DD)	With two seals

a_max	100	m/s²
Maschinenschutz	0,05	kg
Losbrechkraft	1	N
Toleranz des Arbeitsbohrungsdurchmessers	+ 9 - 1
Betriebsbedingungen	Operating conditions

v_max	2,50	m/s
F_R (Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. )	0,50	N
Kugelreihen	4
Radialspiel der Welle h6 (Determined from working bore diameter and shaft tolerance statistics. Recommended housing bore tolerance: H6 or H7. )	+ 15 + 2
Zulässige Umgebungstemperatur (min ... max) (Only unsealed Linear Bushings with steel ball retainers may be used at higher temperatures. Make allowance for reductions in load capacity. )	-10 °C ... +80 °C
