1)
Funnel-type lube nipple AM8 x 1 for lube version LSS/LPG; lubrication possible from two sides
(central lubrication only necessary with grease press on one of the two sides).
2)
Detail A, size 90, 110 and 145
3)
Detail A, size 200
4)
Detail B
| Baugröße | 110 | ||
| C | 16 | mm | |
| D2 | 20 | mm | |
| E1 | - | ||
| E3 | 20 | mm | |
| G1 | 6 | 3 Verstellelemente | |
| G3 | 9,50 | ||
| G5 | 4,80 | ||
| H2 | 12 | mm | |
| H4 | 7,70 | mm |
| Industriekomponente | 110 | mm | |
| D1 | 20 | mm | |
| Außendurchmesser | 9 ‒ 2.1 mm deep | ||
| Toleranz für E1 | - | ||
| Toleranz für E3 | ± 0.01 | ||
| G2 | 5,20 | 3 Verstellelemente | |
| G4 | 2,50 | ||
| H1 | 6 | mm | |
| H3 | 3,50 | mm | |
| Wagenlänge Lca | 110 |
| Baugröße | 110 |
| Maschinenschutz | 0,38 | kg |
