| ras max - Max shaft & housing fillet radius | 2 mm | ||
| BSF - Characteristic rolling element frequency | 13,627 Hz | ||
| BPFI - Characteristic inner ring frequency | 14,485 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Oil lubrication limit speed | 5000 tr/min | ||
| C0r - Static load rating | 188 kN | ||
| Radial clearance class | CN | ||
| Lubrication hole on outer ring | Yes | ||
| Brand | NTN |
| Da max - Max shoulder diameter OR | 87 mm | ||
| FTF - Characteristic cage frequency | 0,464 Hz | ||
| BPFO - Characteristic outer ring frequency | 12,515 Hz | ||
| Tmin - Min operating temperature | -20 °C | ||
| Nlim - Grease lubrication limit speed | 3300 tr/min | ||
| Cr - Dynamic load rating | 96 kN | ||
| k - Hole diameter | 3,5 mm | ||
| rs - Min fillet radius | 2 mm |
