| dust protection seal | SS - With End Seal And Side Seal And Inner Seal | ||
| preload | no preload | ||
| outer dimensions - widthw - mm | 86 | ||
| block dimensions - b - mm | 60 | ||
| block dimensions - s x l - mm | m10 x 17 | ||
| rail dimensions - d1xd2xh - mm | 14x20x17 | ||
| basic load rating - radial - static c0 - kn | 101 |
| Baugröße | 45 | ||
| outer dimensions - heightm - mm | 70 | ||
| outer dimensions - lengthl - mm | 139 | ||
| block dimensions - c - mm | 60 | ||
| rail dimensions - pitch f - mm | 105 | ||
| basic load rating - radial - dynamic c - kn | 82,20 |
