| Dimension B2 | 17,50 | mm | |
| Abmessung M | 3,61 | mm | |
| Angle between Set Screws | 90 º | ||
| Set Screw Size | 5/16-18 | ||
| Radius r | 0,60 | mm | |
| Inner Ring Width B | 36,51 | mm |
| Abmessung B1 | 50 | mm | |
| Abmessung d1 | 49,20 | mm | |
| Number of Set Screws | 2 | ||
| Center of Bearing from End S | 17,50 | mm | |
| Outside Ring Width C | 20 | mm | |
| Outside Diameter D | 72 | mm |
| Gewicht | 0,20 | Kg | |
| Sub Series | GN..KRRB | ||
| O.D. Type | Spherical OD | ||
| Material | Bearing Steel | ||
| Bore Type | Cylindrical bore | ||
| Manufacturing Part Number | GN103KRRB + COL |
| Seal Type | Shroud Seal | ||
| Baureihe | Medium-Duty | ||
| Schmierausführung | Relubricatable | ||
| Bearing Type | Ball Bearing | ||
| Shaft Size d | 1 3/16 in |
