EATON FWP-70B

Name: FWP-70B EATON
Brand: EATON
SKU: 801846-de-eur
Price: 62.9 EUR
Availability: InStock

62,90 €

1 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Einbaulage	stud
Breite	25 mm

Gewicht	108g

packaging type		standard
Anwendung		semiconductor, dc common bus, dc drives, power converters/rectifiers
class		class ar
fuse shape		center bolted tags
watt losses		18 w
mounting dimension		m8
Color		none
clearing (i2t)		2000 at 700 v
fuse indicator		non indicating
rated switching capacity		200 a
amperage rating		700 a
current type		ac/dc
center-to-center distance of connections		91.5 mm
rated voltage dc		700 v
compliances		ce marked rohs compliant
Produktgewicht		108 g
product height		25 mm
ean		5027590021821

voltage type		ac/dc
pre arc (i2t)		305
breaking capacity		200 ka
Typ		high speed fuse
utilization category		ar (accompanied semiconductor protection)
Anschluss		blade end x blade end
rated voltage ac		700 v
construction size		other
voltage rating		700 vac, 700 vdc (ul)
fuse type		fwp-b
mounting method		stud
insulated metal gripping lugs (imgl)		no
interrupt rating		50 kaic at 700 vdc 200 kaic vac
certifications		ul recognized csa certified
warranty		not applicable
product width		25 mm
product length/depth		112 mm
UPC		051712796019
