| ean | 4015082790530 | ||
| product height | 2.76 in | ||
| Produktgewicht | .5 lb | ||
| certifications | csa std. c22.2 no.235 iec 60947-2 ul 1077 |
||
| number of poles | four-pole | ||
| Typ | ul 1077 industrial miniature circuit breaker - supplementary protector | ||
| circuit protection | c curve | ||
| interrupt rating | 15 kaic | ||
| Anwendung | suitable for applications where medium levels of inrush current are expected |
| product length/depth | 2.76 in | ||
| product width | 2.9 in | ||
| warranty | 1 year | ||
| catalog notes | positioned for medium inrush startup currents to provide protection for small transformers and pilot devices. | ||
| terminals | standard | ||
| amperage rating | 4 a | ||
| frequency rating | 50-60 hz | ||
| trip type | 5-10x /n |
