| Werkstoff-Hinweis | RoHS-compliant | ||
| Produktgewicht | 1.120 g | ||
| Schutzart | IP20 | ||
| Lagertemperatur | -40 °C ... 85 °C | ||
| CE-Zeichen (siehe Konformitätserklärung) | To EU EMC Directive To EU Low Voltage Directive | ||
| Mains frequency | 45 Hz ... 65 Hz | ||
| Input voltage range AC | 100 V ... 240 V | ||
| Nominal output voltage DC | 48 V | ||
| Primary supply | Single-phase | ||
| Length | 160 mm | ||
| Breite | 42 mm |
| Befestigungsart | With H-rail | ||
| Umgebungstemperatur | -25 °C ... 70 °C | ||
| Relative Luftfeuchtigkeit | 95 % | ||
| LABS-Konformität | VDMA24364 zone III | ||
| Zulassung | c UL us listed (OL) | ||
| Power failure bridging | 15 ms | ||
| Nominal output current | 5 A | ||
| Input current | 1.2 - 2.9 A | ||
| Einbaulage | Free convection | ||
| Höhe | 130 mm |
