| seal material | acrylonitrile butadiene rubber | ||
| Gewicht | 0.08 kg | ||
| Medium | compressed air | ||
| min. medium temperature | -10 °c | ||
| min. ambient temperature | -10 °c | ||
| regulation range min. | 1 bar | ||
| working pressure min. | 1 bar | ||
| compressed air connection output | Ø 4 | ||
| compressed air connection input | g 1/4 |
| Gehäusematerial | brass, polyamide | ||
| qn 1▶2 | 600 l/min | ||
| max. medium temperature | 70 °c | ||
| max. ambient temperature | 70 °c | ||
| regulation range max. | 8 bar | ||
| working pressure max | 16 bar | ||
| compressed air connection type output | external thread | ||
| compressed air connection type input | plug-in with tube nut | ||
| Typ | poppet valve |
