NTN 5211S C3

Name: 5211S C3 NTN
Brand: NTN
SKU: 596180-de-eur
Price: 116.51 EUR
Availability: InStock

55mm x 100mm x 33,3

116,51 €

50+ Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Außendurchmesser	100mm
Gewicht	936g

Brand		NTN
α - Contact angle		25 °
Radial clearance class		C3
C0 - Static load		49 kN
Nlim - Oil lubrication limit speed		5600 tr/min
Tmin - Min operating temperature		-40 °C
BPFO - Characteristic outer ring frequency		4,683 Hz
FTF - Characteristic cage frequency		0,426 Hz
da min - Min shoulder diameter IR		64 mm
ra max - Max shaft & housing fillet radius		1,5 mm

a - Charge load application point		50,1 mm
rs - Min fillet radius		1,5 mm
C - Dynamic load		56 kN
Cu - Fatigue limit load		3 kN
Nlim - Grease lubrication limit speed		4300 tr/min
Tmax - Max operating temperature		120 °C
BPFI - Characteristic inner ring frequency		6,317 Hz
BSF - Characteristic rolling element frequency		5,968 Hz
Da max - Max shoulder diameter OR		91 mm
