| dash number | -6 | ||
| cover material | polyurethane | ||
| Gewicht | 0.05 lb/ft, 0.08 kg/m | ||
| cover color | black | ||
| compatible fitting | 54 series | ||
| Maximale Betriebstemperatur | 212 °f, 100 °c | ||
| hose outside diameter | 0.560 inch, 14.2 mm | ||
| design factor | 4:1 | ||
| specifications met | msha accepted, msha accepted |
| hose reinforcement material | high tensile steel wire braid | ||
| hose inner tube material | copolyester | ||
| Anwendung | fluid handling, construction, hydraulic, manufacturing, agriculture, industrial, forestry, pneumatics, instrumentation, material handling, packaging | ||
| media | air, hydraulic fluid, oil | ||
| minimum bend radius | 2 inch, 51 mm | ||
| maximum operating pressure | 1500 psi, 10.3 mpa, 103 bar | ||
| Minimale Betriebstemperatur | -40 °c, -40 °f | ||
| hose inside diameter | 3/8 inch, 10 mm | ||
| hose i.d. (inch) | 3/8 |
