| mounting orientation | any | ||
| max. particle size | 40 µm | ||
| max. ambient temperature | 60 °c | ||
| max. medium temperature | 60 °c | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| logic function | pneumatic/mechanic counter, adding | ||
| compressed air connection input | m5 | ||
| working pressure max | 8 bar | ||
| pulse duration return | > 180 ms | ||
| pause duration return | > 50 ms |
| Medium | compressed air | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| Anzeige | 6 digits | ||
| return | pneumatic > 2 bar | ||
| working pressure min. | 2 bar | ||
| pulse duration counting | > 18 ms | ||
| pause duration counting | > 10 ms | ||
| Gewicht | 0.08 kg |
