| r1a - Max fillet radius | 1,5 mm | ||
| Cb - Min clearance | 9 mm | ||
| Db min - Min OR shoulder diameter | 120 mm | ||
| Da min - Min shoulder diameter OR | 107 mm | ||
| da max - Max shoulder diameter IR | 79 mm | ||
| FTF - Characteristic cage frequency | 0,429 Hz | ||
| BPFO - Characteristic outer ring frequency | 8,154 Hz | ||
| Tmin - Min operating temperature | -40 °C | ||
| Nlim - Oil lubrication limit speed | 3900 tr/min | ||
| Y0 - Static axial load coefficient | 0,81 | ||
| A2 - Rating life coefficient | 1 | ||
| C0 - Static load | 282 kN | ||
| ISO 355 reference | T3EE070 | ||
| rs - Min fillet radius | 2 mm | ||
| T - Total width | 41 mm | ||
| Brand | NTN |
| ra max - Max fillet radius | 2 mm | ||
| Ca - Min clearance | 7 mm | ||
| Da max - Max shoulder diameter OR | 116,5 mm | ||
| db min - Min IR shoulder diameter | 80 mm | ||
| BSF - Characteristic rolling element frequency | 6,671 Hz | ||
| BPFI - Characteristic inner ring frequency | 10,846 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Grease lubrication limit speed | 2900 tr/min | ||
| Y2 - Upper axial load coefficient | 1,47 | ||
| e - Coefficient | 0,41 | ||
| Cu - Fatigue limit load | 34,5 kN | ||
| C - Dynamic load | 223 kN | ||
| r1s - Min fillet radius | 1,5 mm | ||
| a - Charge load application point | 31 mm | ||
| C - Outer ring width | 32 mm |
