| Gewicht | 0.003 kg | ||
| suction unit material | fluoromethyl silicone | ||
| connection thread type | external thread | ||
| abrasion value according to din 535 16 | 100-120 mm³ | ||
| Volumen | 0.065 cm³ | ||
| external diameter | 10 mm | ||
| temporary ambient temperature (<30 s) max. | 220 °c | ||
| temperature resistance | heat resistant | ||
| min. ambient temperature | -30 °c |
| delivery unit | 1 piece | ||
| Material connector | aluminum | ||
| hardness according to standard | 55 ± 5 shore a | ||
| max. curving on object rmin | 9 mm | ||
| Haltekraft | 4 n | ||
| compressed air connection | m5 | ||
| temporary ambient temperature (<30 s) min. | -50 °c | ||
| max. ambient temperature | 180 °c |
