| min. ambient temperature | -10 °c | ||
| temporary ambient temperature (<30 s) min. | -30 °c | ||
| compressed air connection | g 1/8 | ||
| Haltekraft | 4 n | ||
| max. curving on object rmin | 13 mm | ||
| hardness according to standard | 55 ± 5 shore a | ||
| Material connector | aluminum | ||
| delivery unit | 2 piece |
| max. ambient temperature | 70 °c | ||
| temporary ambient temperature (<30 s) max. | 120 °c | ||
| external diameter | 10 mm | ||
| Volumen | 0.07 cm³ | ||
| abrasion value according to din 535 16 | 100-120 mm³ | ||
| connection thread type | external thread | ||
| suction unit material | acrylonitrile butadiene rubber | ||
| Gewicht | 0.0016 kg |
