| port 1 | g 3/4 | ||
| throttle bore Ø | 17.5 mm | ||
| nominal flow qn 1 to 2 | 5400 l/min | ||
| compressed air connection type 2 | internal thread | ||
| working pressure min. | 0.5 bar | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| Gewicht | 0.64 kg | ||
| material flow control screw | steel |
| port 2 | g 3/4 | ||
| direction of throttle | 1 ▶ 2, 2 ▶ 1 | ||
| compressed air connection type 1 | internal thread | ||
| Medium | compressed air | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 80 °c | ||
| max. medium temperature | 80 °c | ||
| Gehäusematerial | aluminum | ||
| seal material | acrylonitrile butadiene rubber |
