NORGREN 03062502 super x 3/2 manual valve

Name: 03062502 NORGREN
Brand: NORGREN
SKU: 779408-de-eur
Price: 232.76 EUR
Availability: SoldOut

232,76 €

Begrenzter Lagerbestand nur auf Anfrage erhältlich

Technische Daten

Actuation Type	knob / knob
max. Druck	-0.9 ... 10 bar

Dichtung	nitrile rubber
Gewicht	360g

actuation		knob / knob
data performance b10 value number of cycles		1000000
eu country of origin		czechia
flow flow litresperminute		965 l/m
Medium		compressed air
operating pressure pressure bar min to max range		-0.9 ... 10 bar
operating temperature f temperature fahrenheit min to max range		32 ... 158 °f
operator 10		knob
Anschlussgröße		g1/4
product style		manual
Dichtungen		nitrile rubber
valve operation		3/2

body		zinc
data performance shelf life		3 years
flow flow dm3sec		16.08 dm3/sec
fluid temperature temperature celsius min to max range		0 ... 70 °c
mil spec		available on request
operating pressure psi pressure psi min to max range		-13 ... 145 psi
operating temperature temperature celsius min to max range		0 ... 70 °c
operator 12		knob
port type		female thread
range		super x
Thread Type		bspp
