NORGREN 03060402 super x 3/2 manual valve

Name: 03060402 NORGREN
Brand: NORGREN
SKU: 781169-de-eur
Price: 185.32 EUR
Availability: InStock

185,32 €

1 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Actuation Type	knob / spring return
max. Druck	-0.9 ... 10 bar

Dichtung	nitrile rubber

actuation		knob / spring return
data performance b10 value number of cycles		1000000
eu country of origin		czechia
flow imperial flow scfm		34 scfm
Medium		compressed air
operating pressure pressure bar min to max range		-0.9 ... 10 bar
operating temperature f temperature fahrenheit min to max range		32 ... 158 °f
Anschlussgröße		g1/4
range		super x
valve operation		3/2

body		zinc
data performance shelf life		3 years
flow flow litresperminute		965 l/m
fluid temperature temperature celsius min to max range		0 ... 70 °c
mil spec		available on request
operating pressure psi pressure psi min to max range		-13 ... 145 psi
operating temperature temperature celsius min to max range		0 ... 70 °c
product style		manual
Dichtungen		nitrile rubber
