FESTO VSCS
26 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VSCS – Standards-based valve to ISO 15218. Finden Sie das passende Produkt durch Filtern mit Handhilfsbetätigung, Nominal operating voltage, Elektrischer Anschluss und Pressure range [MPa] 0 ... 1.
VSCS Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VSCS | VSCS-B- -M- | Standards-based valve to ISO 15218 |
Typcode zur Katalognummer VSCS,
VSCS-B- -M-
| 001 | Series |
|---|---|
| VSCS | Standards-based valve to ISO 15218 |
| 002 | Directional control valve type |
| B | Sub-base valve |
| 003 | Valve function |
| M32 | 3/2-way solenoid valve |
| M32C | 3/2-way valve, normally closed |
| 004 | Reset method for monostable/single solenoid valves |
| M | Mechanical spring |
| 005 | Manual override |
| None | |
| D | Non-detenting, detenting |
| H | Non-detenting |
| T | Non-detenting, detenting with accessories |
| 006 | Pneumatic connection |
| WA | Sub-base size 15 mm to ISO 15218 (CNOMO) |
| WB | Sub-base size 30 mm to ISO 15218 (CNOMO) |
| 007 | Nominal operating voltage |
| None | |
| 1 | 24 V DC |
| 1A | 24 V AC/50-60 Hz |
| 2A | 110 V AC/50-60 Hz |
| 3A | 230 V AC/50-60 Hz |
| 5 | 12 V DC |
| 008 | Electrical connection |
|---|---|
| None | |
| C1 | Plug pattern type C, to EN 175301-803 |
| E1 | Plug pattern type C, industry standard |
| R3 | Individual plug M12, to EN 61076-2-101 |
| 009 | Valve pilot control interface |
| Standard | |
| F8 | With armature tube 8 mm, long |
| 010 | Pressure range [MPa] 0 ... 1 |
| 0 ... 1 | |
| 8 | 0.15 ... 0.8 |
