FESTO VOFD
14 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VOFD – Solenoid valve, series D. Finden Sie das passende Produkt durch Filtern mit Nominal width, Pneumatischer Anschluss, Exhaust, Pressure range [bar], Corrosion protection, Valve pilot control interface, Power consumption, Nominal operating voltage, Elektrischer Anschluss, EU certification und Type of ignition protection.
VOFD Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VOFD | VOFD-L- -T- -M-N- - | Solenoid valve, series D |
Typcode zur Katalognummer VOFD,
VOFD-L- -T- -M-N- -
| 001 | Series |
|---|---|
| VOFD | Solenoid valve, series D |
| 002 | Directional control valve type |
| L | In-line valve |
| 003 | Nominal width |
| 12 | 1.2 mm |
| 35 | 3.5 mm |
| 50 | 5 mm |
| 100 | 10 mm |
| 004 | Design principle |
| T | Poppet valve |
| 005 | Valve function |
| M32A | 3/2-way valve, normally closed, semi-automatic |
| M32 | 3/2-way valve, normally closed or open |
| 006 | Reset method for monostable/single solenoid valves |
| M | Mechanical spring |
| 007 | Pilot air |
| N | None |
| 008 | Manual override |
| None | |
| H | Non-detenting |
| Y | Detenting |
| 009 | Pneumatic connection |
| FG12 | NAMUR port pattern 1/4, connections G1/2 |
| FG14 | NAMUR port pattern 1/4, connections G1/4 |
| FGP14 | NAMUR port pattern 1/4, connections G1/4 with extended NA- |
| MUR interface | |
| FNP14 | NAMUR port pattern 1/4, connections 1/4 NPT with extended NAMUR interface |
| G14 | G1/4 |
| G12 | G1/2 |
| N14 | 1/4 NPT |
| N12 | 1/2 NPT |
| 010 | Supply connection version |
| Standard | |
| PF | With particle fi lter |
| NPF | With particle fi lter and connecting thread NPT |
| 011 | Exhaust |
| No fitting | |
| U6 | With exhaust protection |
| UE | Quick exhaust function |
| 012 | Pressure range [bar] |
| 8 | 0 ... 8 |
| 10 | 0 ... 10 |
| 12 | 0 ... 12 |
| 013 | Temperature range |
| Standard | |
| T6 | -50 ... +60°C |
| 014 | Corrosion protection |
| Standard |
| R1 | Stainless steel |
| R16 | Brass |
| 015 | Valve pilot control interface |
|---|---|
| F10 | Electric with armature tube for solenoid coil, 18 mm |
| F19 | Electric with armature tube for solenoid coil, 13 mm |
| F19A | Electric with armature tube for solenoid coil 13 mm, intrinsically safe |
| 016 | Power consumption |
| None | |
| 18 | 1.8 W |
| 25 | 2.5 W |
| 35 | 3.5 W |
| 70 | 7 W |
| 120 | 12 W |
| 017 | Nominal operating voltage |
| None | |
| 1 | 24 V DC |
| 1A | 24 V AC/50-60 Hz |
| 1U | 24 V DC and AC |
| 2A | 110 V AC/50-60 Hz |
| 2U | 110 V DC and AC |
| 3 | 230 V DC |
| 3A | 230 V AC/50-60 Hz |
| 3U | 230 V DC and AC |
| 7 | 48 V DC |
| 7U | 48 V DC and AC |
| 16 | 120 V DC |
| 16U | 120 V DC and AC |
| 27 | 60 V DC |
| 018 | Electrical connection |
| None | |
| A1 | Plug pattern type A, to EN 175301-803 |
| K4 | Cable connector metric |
| K5 | Cable connector NPT |
| 019 | Circuitry |
| None | |
| F | Fuse |
| 020 | EU certification |
| None | |
| EX4 | II 2GD |
| 021 | Certification |
| None | |
| U2 | cULus, hazardous environment, USA and Canada (NEC 500, Class 1 Div 2) |
| 022 | Type of ignition protection |
| None | |
| A | Intrinsically safe |
| D | Flameproof encapsulation |
| ME | Encapsulation, enhanced security |
