FESTO VN
169 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VN – Vacuum generator. Finden Sie das passende Produkt durch Filtern mit Nominal width of Laval nozzle, Ejector characteristics, Housing type, Compressed air connection, Vakuumanschluss, Schaltfunktion, Electrical output, Exhaust port, Integrierte Funktion und Special material properties.
VN Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VN | VN- - - - - | Vacuum generator |
Typcode zur Katalognummer VN,
VN- - - - -
| 001 | Series |
|---|---|
| VN | Vacuum generator |
| 002 | Nominal width of Laval nozzle |
| 05 | 0.45 mm |
| 07 | 0.70 mm |
| 10 | 0.95 mm |
| 14 | 1.4 mm |
| 20 | 2.0 mm |
| 30 | 3.0 mm |
| 003 | Ejector characteristics |
| H | High vacuum/standard |
| L | High suction rate/standard |
| M | High vacuum/inline |
| N | High suction rate/inline |
| 004 | Housing type |
| I2 | Straight shape, pitch 10 mm |
| I3 | Straight shape, pitch 13 mm |
| T2 | T-shape, pitch 10 mm |
| T3 | T-shape, pitch 14 mm |
| T4 | T-shape, pitch 18 mm |
| T6 | T-shape, pitch 24 mm |
| 005 | Compressed air connection |
| PQ1 | Push-in connector 4 mm |
| PQ2 | Push-in connector 6 mm |
| PQ3 | Push-in connector 8 mm |
| PQ4 | Push-in connector 10 mm |
| PI2 | Female thread M5 |
| PI4 | Female thread G1/8 |
| PI5 | Female thread G1/4 |
| 006 | Vacuum connection |
| VQ1 | Push-in fitting QS-4 |
| VQ2 | Push-in fitting QS-6 |
| VQ3 | Push-in fitting QS-8 |
| VQ5 | Push-in fitting QS-12 |
| VI2 | Female thread M5 |
| VI4 | Female thread G1/8 |
| VI5 | Female thread G1/4 |
| VI6 | Female thread G3/8 |
| VA4 | Male thread G1/8 |
| VA5 | Male thread G1/4 |
| VT1 | Push-in sleeve 4 mm |
| VT2 | Push-in sleeve 6 mm |
| 007 | Switching function |
|---|---|
| None | |
| O1 | Threshold value with fi xed hysteresis, 2 teach-in points, N/O contact |
| O2 | Threshold value with variable hysteresis, N/O contact |
| 008 | Electrical output |
| None | |
| P | Switching output PNP |
| 009 | Exhaust port |
| None | |
| RQ1 | Push-in fitting QS-4 |
| RQ2 | Push-in fitting QS-6 |
| RQ3 | Push-in fitting QS-8 |
| RI2 | Female thread M5 |
| RI4 | Female thread G1/8 |
| RI5 | Female thread G1/4 |
| RO1 | Silencer UO |
| RO2 | Silencer UOM |
| 010 | Integrated function |
| None | |
| A | Ejector pulse, pneumatic |
| B | Electric on/off valve and pneumatic ejector pulse |
| M | Electric on/off valve |
| 011 | Special material properties |
| None | |
| F1A | Recommended for production facilities for the manufacture of lithium-ion batteries |
