FESTO VEMP
8 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO VEMP – Piezo valve. Finden Sie das passende Produkt durch Filtern mit Nominal width [mm], Pressure range [bar], Nominal operating voltage und Package unit quantity.
VEMP Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| VEMP | VEMP-B-S-3- - -F- -T1 | Piezo valve |
Typcode zur Katalognummer VEMP,
VEMP-B-S-3- - -F- -T1
| 001 | Series |
|---|---|
| VEMP | Piezo valve |
| 002 | Directional control valve type |
| B | Sub-base valve |
| 003 | Design principle |
| S | Bending actuator |
| 004 | Valve function |
| 3 | 3/3-way valve, normally closed |
| 005 | Nominal width [mm] |
| 13 | 1.3 |
| 16 | 1.6 |
| 006 | Pressure range [bar] |
| D5 | 0 ... 0.5 |
| D7 | 0 ... 1 |
| D19 | 0 ... 1.7 |
| 007 | Pneumatic connection |
|---|---|
| F | Flange/sub-base |
| 008 | Nominal operating voltage |
| 22 | 250 V DC |
| 28 | 310 V DC |
| 009 | Electrical connection |
| T1 | Pin |
| 010 | Package unit quantity |
| Standard | |
| P30 | 30 |
