| Baureihe | vchn3 | ||
| max. operating pressure (mpa) | 5.0 (solenoid valve inlet pressure) | ||
| Anschlussgröße | r3/4 | ||
| sound absorbing material effective area (single) (mm2) | 420 | ||
| ambient temperature (c) | 5 to 80 | ||
| Gewicht | 1.46371 lb |
| fluid | air, insert gas | ||
| relief valve unlocking pressure (mpa) | 1,80 | ||
| effective area (mm2) | 200 | ||
| fluid temperature (c) | 5 to 80 | ||
| noise reduction db(a) | 35 (supply pressure 4.0 mpa, back pressure 2.0 mpa) |
