| Brand | SNR | ||
| A1 - Housing foot height / flange height | 10 mm | ||
| e - Distance mounting surface to bearing center | 19 mm | ||
| J - Mounting holes distance | 63,5 mm | ||
| N - Mounting hole dimension | 11,5 mm | ||
| C - Dynamic load rating | 12,8 kN | ||
| Operating temperature min. | -20 °C | ||
| Recommended tightening torque for set screw | 3,7 N-m |
| A - Housing height | 29,5 mm | ||
| A2 - Total height from mounting surface | 37,3 mm | ||
| G - Grease fitting | R1/8" | ||
| L - Housing width / diameter | 86 mm | ||
| S - Dist. cent. of raceway to face IR on side opp. lock. device | 12,7 mm | ||
| C0 - Static load rating | 6,65 kN | ||
| Operating temperature max. | 100 °C |
