| Rolling element frequency (60 t./min.) | 4,841 Hz | ||
| Inner ring frequency (60 t./min.) | 5,393 Hz | ||
| Recommended tightening torque for set screw | 11,5 N-m | ||
| Operating temperature min. | -40 °C | ||
| C - Dynamic load rating | 29,6 kN | ||
| S - Dist. cent. of raceway to face IR on side opp. lock. device | 19 mm | ||
| m - Distance to set screw | 8 mm | ||
| C1 - Distance center of OR to center of lubrication zone | 6,3 mm | ||
| Brand | SNR |
| Cage frequency (60 t./min.) | 0,401 Hz | ||
| Outer ring frequency (60 t./min.) | 3,607 Hz | ||
| Operating temperature max. | 100 °C | ||
| C0 - Static load rating | 18,2 kN | ||
| SW - Wrench size | 4 mm | ||
| r - Radius Inner Ring | 1,10 | ||
| G - Set screw size | M8x1 | ||
| C - Width of Outer Ring | 21 mm |
