| Chamfer dimension inner ring | r1,2 | min.0.3 | |
| Raceway diameter inner ring | F | 30 | mm |
| Width Inner ring | B | 16 | mm |
| Bore diameter | d | 25 | mm |
| Chamfer dimension outer ring | r1,2 | min.0.3 | |
| Raceway diameter outer ring | E | 37 | mm |
| Width Outer ring | C | 15,80 | mm |
| Außen-Ø | d2 | 52 | mm |
| Hersteller | Teilenummer |
|---|---|
| INA | STO25 (INA) |
