FESTO SOPA
28 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO SOPA – Air gap sensor for contact and distance monitoring with LCD display. Finden Sie das passende Produkt durch Filtern mit Modules, Manual override control module, Befestigungsart, Electrical output 1 und Electrical output 2.
SOPA Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| SOPA | SOPA- -R1- -Q6- -M12 | Air gap sensor for contact and distance monitoring with LCD display |
Typcode zur Katalognummer SOPA,
SOPA- -R1- -Q6- -M12
| 001 | Series |
|---|---|
| SOPA | Air gap sensor for contact and distance monitoring with LCD display |
| 002 | Modules |
| CM1 | Control module with a sensor module |
| CM2 | Control module with two sensor modules, pneumatically linked |
| CM3 | Control module with three sensor modules, pneumatically linked |
| CM4 | Control module with four sensor modules, pneumatically linked |
| M1 | Sensor module |
| 003 | Manual override control module |
| None | |
| H | With |
| 004 | Sensing range |
| R1 | 20 ... 200 µm |
| 005 | Type of mounting |
| H | H-rail mounting |
| W | Wall mounting |
| 006 | Pneumatic connection |
| Q6 | Push-in connector 6 mm |
| 007 | Electrical output 1 |
|---|---|
| 2N | 2x NPN |
| 2P | 2x PNP |
| PNLK | PNP or NPN or IO-Link® |
| 008 | Electrical output 2 |
| None | |
| VB | 0 ... 10 V or 1 ... 5 V |
| A | 4 ... 20 mA |
| 009 | Electrical connection |
| M12 | Plug M12, A-coded |
| 010 | Electrical accessories |
| None | |
| E1 | Straight socket, cable 2.5 m |
| E2 | Straight socket, cable 5 m |
| E3 | Angled socket, cable 2.5 m |
| E4 | Angled socket, cable 5 m |
