FESTO SME
45 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO SME – Proximity sensor. Finden Sie das passende Produkt durch Filtern mit Design type, Electrical connection, cable length, outlet orientation of connection, Schaltausgang, Rated operating voltage, Leitungseigenschaft, Cable length [m] und Connection technology.
SME Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| SME | SME-10-M- -24- -L- - | Proximity sensor |
| SME | SME-8-- -K- -OE | Proximity sensor |
| SME | SME-8-M- - - - | Proximity sensor |
| SME | SME-10- -LED-24 | Proximity sensor |
Typcode zur Katalognummer SME,
SME-10-M- -24- -L- -
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 10 | For round slot |
| 003 | Sensor version |
| M | Inserted in the slot from above |
| 004 | Switching output |
| DS | 3-wire N/O contact |
| ZS | 2-wire PNP N/O contact |
| 005 | Rated operating voltage |
| 24 | 24 V DC |
| 006 | Cable characteristic |
| None | |
| E | Suitable for energy chains/robot applications |
| 007 | Cable length [m] |
| ... | 0.2 ... 10 m |
| 008 | Display |
|---|---|
| L | LED |
| 009 | Cable outlet |
| Q | Transverse |
| L | Longitudinal |
| 010 | Cable identification |
| With label holder | |
| N | Without label holder |
| 011 | Connection technology |
| OE | Open end |
| M8 | M8, snap-on fl ange |
| M8D | M8, rotatable thread |
| M12 | M12, rotatable thread |
Typcode zur Katalognummer SME,
SME-8-- -K- -OE
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 8 | For T-slot |
| 003 | Sensor version |
| Inserted in the slot lengthwise | |
| 004 | Switching output |
| None | |
| O | N/C contact, 3-wire |
| ZS | 2-wire PNP N/O contact |
| 005 | Switching status indication |
| None |
| LED | Yellow LED |
| 006 | Rated operating voltage |
|---|---|
| 24 | 24 V DC |
| 230 | 230 V AC |
| 007 | Cable characteristic |
| K | Standard/suitable for energy chains |
| 008 | Cable length [m] |
| 5,0 | 5.0 m |
| 7,5 | 7.5 m |
| 009 | Electrical connection |
| OE | Open end |
Typcode zur Katalognummer SME,
SME-8-M- - - -
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 8 | For T-slot |
| 003 | Sensor version |
| M | Inserted in the slot from above |
| 004 | Switching output |
| DO | 3-wire N/C contact |
| DS | 3-wire N/O contact |
| ZS | 2-wire PNP N/O contact |
| 005 | Rated operating voltage |
| None |
| 24V | 24 V |
| 006 | Cable characteristic |
|---|---|
| E | Suitable for energy chains/robot applications |
| K | Standard/suitable for energy chains |
| 007 | Cable length [m] |
| ... | 0.2 ... 10 m |
| 008 | Connection technology |
| OE | Open end |
| M8 | M8, snap-on fl ange |
| M8D | M8, rotatable thread |
| M12 | M12, rotatable thread |
Typcode zur Katalognummer SME,
SME-10- -LED-24
| 001 | Series |
|---|---|
| SME | Proximity sensor |
| 002 | Design type |
| 10 | For round slot, insertable in the slot lengthwise |
| 003 | Electrical connection, cable length, outlet orientation of connection |
| KL | Cable, 2.5 m, in-line |
| KQ | Cable, 2.5 m, lateral |
| SL | Plug M8x1 with cable, 0.3 m, in-line |
| SQ | Plug M8x1 with cable, 0.3 m, lateral |
| 004 | Switching status indication |
|---|---|
| LED | Yellow LED |
| 005 | Rated operating voltage |
| 24 | 24 V DC |
