| adjusting knob | plated steel | ||
| body | aluminium | ||
| data performance shelf life | 3 years | ||
| flow flow dm3sec | 170 dm3/sec | ||
| gauge | no gauge | ||
| maximum inlet pressure pressure bar | 4 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 176 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 4 ... 60 psi | ||
| Anschlussgröße | without yoke | ||
| range | r68g | ||
| Baureihe | olympian plus |
| Einstellung | t-bar | ||
| bonnet | aluminium | ||
| elastomers | synthetic rubber | ||
| flow flow dm3secbar | 170 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 58 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.3 ... 4 bar | ||
| product style | plug-in | ||
| relievingnonrelieving | relieving |
