| Standard | iso 5599-1 | ||
| controlled port | 2 | ||
| regulation range min. | 0.5 bar | ||
| min. ambient temperature | -15 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| nominal flow qn | 1070 l/min | ||
| Gewicht | 1.11 kg | ||
| seal material | butadiene rubber |
| frame size | iso 2 | ||
| working pressure max | 12 bar | ||
| regulation range max. | 8 bar | ||
| max. ambient temperature | 50 °c | ||
| max. particle size | 5 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| tightening torque for mounting screws | 5 nm | ||
| Gehäusematerial | aluminum |
