| activation | electrically | ||
| switching principle | 5/2 | ||
| working pressure min. | -0.8 bar | ||
| actuating control | single solenoid | ||
| control pressure min. | 3 bar | ||
| min. ambient temperature | 5 °c | ||
| min. medium temperature | 5 °c | ||
| Medium | compressed air | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| compressed air connection input | base plate | ||
| Ausschaltzeit | <35 | ||
| mounting screw tightening torque | 0.9 nm | ||
| delivery unit | 1 piece |
| nominal flow qn | 610 l/min | ||
| compressed air connection output | Ø 8 | ||
| working pressure max | 8 bar | ||
| return | with spring return | ||
| control pressure max. | 8 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| max. particle size | 40 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| Einschaltzeit | <20 | ||
| mounting screws | hexalobular socket (torx) iso 10664-10 | ||
| tightening torque tolerance | ±0,1 mt |
