| signal connection | input and output | ||
| electrical connection size | m12 | ||
| certificates | ce declaration of conformity | ||
| Typ | poppet valve | ||
| max. particle size | 50 µm | ||
| Schutzklasse | ip65 | ||
| dc operating voltage | 24 v | ||
| min. medium temperature | 5 °c | ||
| min. ambient temperature | 5 °c | ||
| Medium | compressed air | ||
| working pressure max | 18 bar | ||
| regulation range max. | 16 bar | ||
| control | directly controlled |
| electrical connection number of poles | 5-pin | ||
| electrical connection type | plug | ||
| mounting orientation | α = 0 ... 90° ±β = 0 ... 90° | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| permissible ripple | 5% | ||
| Max. Stromaufnahme | 1400 ma | ||
| max. medium temperature | 50 °c | ||
| max. ambient temperature | 50 °c | ||
| nominal flow qn | 1300 l/min | ||
| Hysterese | 0,04 bar | ||
| working pressure min. | 0.5 bar | ||
| regulation range min. | 0 bar |
